Tumbler MPR 150 / 220
19
Protection class: IP54
Protection class: 1
Ambient temperature: +2 to 40 °C
Dimensions, W x H x D
- MPR 150: 1358 x 2447 x 1791 mm
- MPR 220: 1358 x 2447 x 1922 mm
Machine weight
- MPR 150: 650 kg
- MPR 220: 700 kg
Transport weight
- MPR 150: 750 kg
- MPR 220: 800 kg
Container size
- MPR 150: 150 litres
- MPR 220: 220 litres
Max. filling
- MPR 150: 110 litres
- MPR 220: 160 litres
Refrigerant: R404A, 0.75 kg
Speed of mixer and
tumbling arm: 0 to 50 rpm
Vacuum: 0 – 90 %
Foundation load (MPR 150): 6,9 kN/m²
Foundation load (MPR 220): 7,8 kN/m²
Emission sound pressure level: L
pA
≤ 70 dB(A)
Measured according to: DIN EN ISO 11201
in case of uncertainty K
pA
2.5 dB
Measured: while idling without product,
at maximum speed
The data on the type plate principally applies; it is located at the rear
of the machine next to the power supply line. In case of deviations
contact the manufacturer for a written confirmation of the data!
