Ruhle MPR 150 - Workplace Description

Tumbler MPR 150 / 220
8
Observe the maximum filling capacity of 110 litres with
the MKR 150 and 160 litres with the MKR 220 per stand-
ard trolley (corresponds to the max. filling capacity of the
drum)!
Foundation load (MPR 150): 6,9 kN/m²!
Foundation load (MPR 220): 7,8 kN/m²!
Set up the machine on a solid level floor with sufficient
load bearing capacity!
2.2 Workplace description
The work area around the machine is at least 0.5 m on all sides; for
maintenance work it is at least 1 m; if used as passage way, it is at
least 1.2 m.
MPR 150:
Swivel range
of drum
Swivel range of drum
and lid
