Ruijie 5310-E Series User Manual

Hardware Installation and Reference Guide Product Overview
10
Rated Current Per Circuit: 1.5 A
SFP+ Port
10GBase-R Capable
1000Base-X Capable
RTC
Supported
PoE
Not supported
Power Consumption
< 40 W
Operating Temperature
0ºC to 45ºC (32ºF to 113 ºF) at a height below 1800 m (1.12 miles) above the sea level
At a height ranging from 1800 m (1.12 miles) to 5000 m (3.11 miles) above the sea level, the maximum
operating temperature decreases by 1°C (1.8°F) every time the altitude increases by 220 m (721.78
ft.).
Storage Temperature
-40ºC to 70ºC (-40ºF to 158ºF)
Operating Humidity
10% to 90% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above the sea level
Storage Humidity
5% to 95% RH (non-condensing)
Fan
Fan Speed Control
Fan Fault Alarming
Temperature Alarming
Supported
EMI Certification
GB9254-2008CLASS A
Safety Regulation
Compliance
GB4943-2011
Dimensions
(W x D x H)
442 mm x 220 mm x 43.6 mm (17.40 in. x 8.66 in. x 1.72 in.)
Weight
2.7 kg (5.95 lbs.)
Appearance
The front panel of the RG-S5300-24GT4XS-E switch provides 24 10/100/1000Base-T Ethernet ports, four 10GE SFP+ ports, one
management port, one Console port and one USB port. The back panel has an AC power plug.
Figure 1-9 RG-S5300-24GT4XS-E Switch Appearance
Front Panel
