Ruijie 5310-E Series User Manual

Hardware Installation and Reference Guide Product Overview
6
Solid Green
The port has made a successful 1/10 Gbps link.
Blinking Green
The port is sending and receiving traffic at 1/10 Gbps.
10/100/1000Base-T Ethernet
Port LED
1F to 24F
Off
No link is detected for this port.
Solid Green
The port has made a successful 10/100/1000 Mbps
link.
Blinking Green
The port is sending and receiving traffic at
10/100/1000 Mbps.
1.2 RG-S5300-24GT2SFP2XS-E
Specifications
Model
RG-S5300-24GT2SFP2XS-E
CPU
Dual-core CPU with the clock speed of 1.2 GHz
BOOTROM
16 MB
Flash Memory
2 GB
SDRAM
1 GB
SFP and SFP+ Module
Type
SFP Port:
SFP Modules and SFP BIDI Modules.
SFP+ Port:
SFP Modules and SFP BIDI Modules.
SFP+ Modules, SFP+ Cables and SFP BIDI Modules.
See Chapter 7 for details.
The module types may update without prior notification. Please contact Ruijie Networks for
details.
Built-in Power Supply
AC Input
Rated Voltage Range: 100 V AC to 240 V AC
Maximum Voltage Range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 1.5 A
SFP Port
1000Base-X Capable
SFP+ Port
10GBase-R Capable
1000Base-X Capable
RTC
Supported
PoE
Not supported
Power Consumption
< 40 W
Operating Temperature
0ºC to 45ºC (32ºF to 113 ºF) at a height below 1800 m (1.12 miles) above the sea level
At a height ranging from 1800 m (1.12 miles) to 5000 m (3.11 miles) above the sea level, the maximum
operating temperature decreases by 1°C (1.8°F) every time the altitude increases by 220 m (721.78
ft.).
Storage Temperature
-40ºC to 70ºC (-40ºF to 158ºF)
Operating Humidity
10% to 90% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above the sea level
