Hardware Installation and Reference Guide Product Overview
46
The temperature at the air intake and exhaust vents
exceeds the threshold.
1. The temperature at the air intake and exhaust vents
exceeds the threshold greatly.
2. The system is not functioning properly.
The power supply module is not seated.
The power supply module is seated and providing
power to the switch.
The model of the power supply module is not
supported or cannot be identified.
The redundant power supply module is not functioning
properly or not connected with the AC power cord.
No link is detected for this port.
The port has made a successful 1000 Mbps link.
The port is sending and receiving traffic at 1000 Mbps.
The port has made a successful 10/100 Mbps link.
The port is sending and receiving traffic at 10/100
Mbps.
No link is detected for this port.
The port has made a successful 1/10 Gbps link.
The port is sending and receiving traffic at 1/10 Gbps.
No link is detected for this port.
The port has made a successful 100/1000 Mbps link.
The port is sending and receiving traffic at 100/1000
Mbps.
1.13 Power Supply Module
1.13.1 RG-PA70IB Module
The RG-S5310-24GT4XS-E, RG-S5310-48GT4XS-E and RG-S5310-24SFP4XS-E switches support the RG-PA70IB swappable power module.
The RG-PA70IB is an AC module (AC/HVDC input and DC output) providing an output voltage of 12 V and an output power of up to 70
W.
The switch can be powered on by either one power supply module or dual power supply modules. If both power supply modules
are used, the switch works in the power redundancy mode.
At least one power supply module is required. If any slot is unoccupied, install a filler panel to enable proper airflow.
Specifications
RG-S5310-24GT4XS-E, RG-S5310-48GT4XS-E, RG-S5310-24SFP4XS-E
Rated Input Voltage Range
AC Input: 100 V AC to 240 V AC, 50 Hz/60 Hz
