Ruijie 5310-E Series

Hardware Installation and Reference Guide Product Overview
17
SFP+ Port
10GBase-R Capable
1000Base-X Capable
RTC
Supported
PoE
Not supported
Power Consumption
< 55 W
Temperature
0ºC to 45ºC (32ºF to 113 ºF) at a height below 1800 m (1.12 miles) above the sea level
At a height ranging from 1800 m (1.12 miles) to 5000 m (3.11 miles) above the sea level, the maximum
operating temperature decreases by 1°C (1.8°F) every time the altitude increases by 220 m (721.78
ft.).
Storage Temperature
-40ºC to 70ºC (-40ºF to 158ºF)
Operating Humidity
10% to 90% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above the sea level
Storage Humidity
5% to 95% RH (non-condensing)
Fan
Fan Speed Control
Fan Fault Alarming
Temperature Alarming
Supported
EMI Certification
GB9254-2008CLASS A
Safety Regulation
Compliance
GB4943-2011
Dimensions
(W x D x H)
442 mm x 220 mm x 43.6 mm (17.40 in. x 8.66 in. x 1.72 in.)
Weight
3 kg (6.61 lbs.)
Appearance
The front panel of the RG-S5300-48GT2SFP2XS-E switch provides 48 10/100/1000Base-T Ethernet ports, two GE SFP ports, two 10GE
SFP+ ports (The speed is 1000 Mbps by default and can be improved to 10 Gbps if you purchase a license. Without a license, the port
can make a successful link only when the peer end speed is 1000 Mpbs. If configured as a VSL port, the port supports a speed of 10
Gbps without the license), one management port, one Console port and one USB port. The back panel has an AC power input plug.
Figure 1-17 RG-S5300-48GT2SFP2XS-E Switch Appearance
Front Panel
Figure 1-18 Front Panel of RG-S5300-48GT2SFP2XS-E
