Hardware Installation and Reference Guide Product Overview
44
Storage Temperature
-40ºC to 70ºC (-40ºF to 158ºF)
Operating Humidity
10% to 90% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above the sea level
Storage Humidity
5% to 95% RH (non-condensing)
Fan
Fan Speed Control
Fan Fault Alarming
Temperature Alarming
Supported
EMI Certification
GB9254-2008CLASS A
Safety Regulation
Compliance
GB4943-2011
Dimensions
(W x D x H)
442 mm x 420 mm x 43.6 mm (17.40 in. x 16.54 in. x 1.72 in.)
Weight
4.5 kg (9.92 lbs.)
Appearance
The front panel of the RG-S5310-48SFP4XS-E switch provides 48 GE SFP ports, four 10GE SFP+ ports, one management port, one
Console port and one USB port. The back panel has two power supply module slots.
Figure 1-45RG-S5310-48SFP4XS-E Switch Appearance
Front Panel
Figure 1-46 Front Panel of RG-S5310-48SFP4XS-E
1. System Status LED
2. Management Port LED
3. PWR1 Status LED
4. PWR2 Status LED
5. USB Port
6. Console Port
7. Management Port
8. GE SFP Port
9. GE SFP Port LED
10. 10GE SFP+ Port
11. 10GE SFP+ Port LED
