Ruijie 5310-E Series User Manual

Hardware Installation and Reference Guide Product Overview
53
16.61 A (Input Voltage: 90 V AC to 176 V AC, 176 V AC not included)
Maximum Output Power
1000 W (Input Voltage: 176 V AC to 290 V AC or 190 V DC to 290 V DC)
930 W (Input Voltage: 90 V AC to 176 V AC, 176 V AC not included)
PoE Power Consumption
740 W (Dual power supply modules: 1480 W)
Ground Leakage Current
≤ 3.5 mA
Dimensions (W x D x H)
196 mm x 90 mm x 40 mm (7.72 in. x 3.54 in. x 1.57 in.)
Weight
1 kg (2.20 lbs.)
Operating Temperature
-10°C to 55°C (14°F to 131°F)
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Relative Operating
Humidity
5% to 95% RH (non-condensing)
Relative Storage Humidity
5% to 95% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above the sea level
Features
Features
Benefit
Conformal Coating
Moisture-proof, salt spray-proof, mold-proof, insulation-proof and leak-proof
Protection
Undervoltage protection, output overcurrent protection, output overvoltage protection and output
short circuit protection
I2C Communication
The switch can communicate with the power supply module through I2C.
Power Redundancy
System supports 1+1 power redundancy when the power consumption is less than 740 W. Dual power
supply modules are connected in parallel for current sharing.
Hot Swapping
In the power redundancy mode, the power supply module can be replaced when the system is
powered on.
Alarming
When a power fault occurs, the output status LED turns off.
LED
Function
Color
Status
Output Status LED
Off
The power supply module is not connected with a power
cord.
Solid Red
A power output error occurs, including fan fault, output
short-circuit, output overcurrent protection, output
overvoltage protection, power supply failure and overheat
protection.
Solid Green
The power supply module is outputing power normally.
