Hardware Installation and Reference Guide 1 Product Overview
4
Table 1-3 Reset Button Description
Button
Function
Operation
Reset
Reboot
Press the button for 2 seconds, and the device will be
rebooted.
Reset
Press the button for over 5 seconds, and the device will be
reset.
No Action
Press the button for 2 to 5 seconds.
1.4 Device Specification
Table 1-4 Specification
Radio Design
Single-Frequency Dual-Stream
Transmission
Protocol
802.11 a/n/ac
Operating Frequency
5G
Antenna Type
Built-in Directional Antenna, Horizontal 60°, Vertical 30°
Spatial Streams
2
Max Throughput
The 5GHz frequency band provides a wireless transmission speed of up to
867Mbps.
Modulation Types
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps,
64-QAM@48/54Mbps
OFDM: BPSK, QPSK,16QAM, 64QAM, 256QAM
Receiver sensitivity
802.11a: -89 dBm (6 Mbps), -80 dBm (24 Mbps), -76 dBm (36 Mbps), -71 dBm (54
Mbps)
802.11n: -83 dBm@MCS0, -65 dBm@MCS7, -83 dBm@MCS8, -65 dBm@MCS15
802.11ac: -86 dBm(MCS0), -63 dBm(MCS9)
Max Transmit Power
400mw (26dBm) (Single-Stream)
Transmit Power
Adjustment
1 dBm
Dimensions (L x W x
H, without bracket)
147 mm × 76 mm × 37 mm (5.78 in. x 2.99 in. x 1.46 in.)
Weight
0.35 kg (0.77 lbs.)
