Ruijie RG-NBS3200 Series Switches Hardware Installation and Reference Guide Product Overview
19
The RG-NBS3200-48GT4XS-P switch is a class A product. In a domestic environment, this product may cause
radio interference in which case the user may be required to take adequate measures.
Product Appearance
On the front panel, the RG-NBS3200-48GT4XS-P Ethernet switch provides 48 10/100/1000Base-T Ethernet ports and
4 SFP+ ports. On the back panel, it provides an AC power port.
Figure 1-17 Appearance of RG-NBS3200-48GT4XS-P
Front Panel
Figure 1-18 Front Panel of RG-NBS3200-48GT4XS-P
Note:
1. PoE mode switch-over button
2. Port mode LED
3. System status LED
5. 10/100/1000 Base-T Ethernet port
6. Reset button
6. 10GE SFP+ port
The switch reboots after the reset button is pressed for less than 2 seconds.
The switch restores the default factory settings after the reset button is pressed for more than 5 seconds (until the
status LED blinks).
