Ruijie RG-NBS3200 Series Switches Hardware Installation and Reference Guide Product Overview
18
BOOTROM
N/A
Flash Memory
256 MB
SDRAM
DDRIII 512MB
Optical Module
See Appendix B.
The copper cable is not supported.
The supported module type may change at any time. Consult Ruijie Networks for the latest
information.
SFP+ Port
10GBase-R
1000Base-X
Power Supply
 AC input
Rated voltage range: 100V to 240V
Maximum voltage range: 90V to 264V
Frequency: 50/60 Hz
Rated current: 7A
Input Leakage
Current
≤3.5mA
EEE
Supported
PoE
Supports PoE and PoE+.
All RJ45 ports are PoE-capable with the maximum power output of 30W per port.
The overall maximum output power of PoE/PoE+ is 370W.
The available number of PDs is determined by PSE output power and PD input power in
practice.
PoE Mode
Mode A (data pairs 1-2 and 3-6)
Power
Consumption
62W with no PoE load;
448W with PoE full load
Temperature
Operating temperature: 0 ºC to 50ºC
Storage temperature: -40 ºC to 70ºC
Humidity
Operating humidity: 10% to 90% RH
Storage humidity: 5% to 90% RH
Fan
Supports adaptive speed adjustment
Temperature
Alarm
Not supported
EMC Standards
GB9254-2008
EN 55032:2015+AC:2016
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 55035:2017
ETSI EN 300 386 V2.1.1 (2016-07)
Security
Standards
GB4943-2011
EN 62638-1
Dimensions
(W x D x H)
440 mm x 357.6 mm x 43.6 mm (with front panel)
Weight
5.4 kg
