WINCH PARTS LIST（EWD8000）
No.
Part #
Qty
Description
Remark
1
D0800001
3
Terminal Protector
2
D0800100
1
Motor Assembly
3
D0800200
1
Bearing
4
D0800002
2
Screw M6 x 12
5
D0800003
2
Lock Washer Φ6
6
D0800300
1
Gear—Ring Assembly
7
D0800400
1
Gear Carrier Assembly （Input）
8
D0800500
1
Bearing
9
D0800004
1
Motor Bracket
10
D0800005
6
Cap Screw M10 x 35
11
D0800006
6
Lock Washer Φ10
12
D0800007
6
Think Flat Washer Φ10
13
D0800008
4
Hex Nut M10
14
D0800009
2
Bushing—Drum
15
D0800010
2
Ring Seals
16
D0800600
1
Brake / Shaft Assembly
17
D0800011
4
Screw M8x 30
18
D0800012
4
Lock Washer Φ8
19
D0800013
2
Tie Bar
20
D0800700
1
Drum Assembly
21
D0800014
1
Screw M8 x 10
22
D0800015
16
Screw M5x 18
23
D0800016
17
Lock Washer Φ5
24
D0800017
1
End Bearing
25
D0800018
1
Connecting Sleeve
26
D0800800
1
Gear Carrier Assembly （Output）
27
D0800900
1
Gear Carrier Assembly （Intermediate）
28
D0801000
1
Gear Sun Assembly （Intermediate）
29
D0800019
2
Gasket
30
D0800020
1
Gear—Ring
31
D0800021
1
Spring
32
D0800022
1
Steel Ball
33
D0800023
1
Screw M5 x 12
34
D0800024
1
Clutch Handle
35
D0800025
1
Clutch Axes
36
D0800026
1
Positioning Piece Of Clutch
37
D0800027
1
Clutch Seat
38
D0800028
1
Clutch Screw
39
D0800029
8
Flat Washer Φ5
40
D0800030
2
Locknut M10
41
D0801100
1
Roller Fairlead
42
D0800031
1
Mounting Channel
By Choice
43
D0801200
1
Remote Control Switch
44
D0801300
1
Cable Assembly
45
D0800032
1
Strap
46
D0801400
1
Control Section Of U Type Winch
By Choice
47
D0801500
1
Control Section Of S Type Winch
By Choice
48
D0801600
1
Control Section Of F Type Winch
By Choice
