WINCH PARTS LIST（EWD12000）
No.
Part #
Qty
Description
Remark
1
D1200001
3
Terminal Protector
2
D1200100
1
Motor Assembly
3
D1200200
1
Bearing
4
D1200002
2
Screw M6 x 12
5
D1200003
2
Lock Washer Φ6
6
D1200300
1
Gear—Ring Assembly
7
D1200400
1
Gear Carrier Assembly （Input）
8
D1200500
1
Bearing
9
D1200004
1
Motor Bracket
10
D1200005
6
Cap Screw M10 x 35
11
D1200006
6
Lock Washer Φ10
12
D1200007
6
Think Flat Washer Φ10
13
D1200008
4
Hex Nut M10
14
D1200009
2
Bushing—Drum
15
D1200010
2
Ring Seals
16
D1200600
1
Brake / Shaft Assembly
17
D1200011
4
Screw M8x 30
18
D1200012
4
Lock Washer Φ8
19
D1200013
2
Tie Bar
20
D1200700
1
Drum Assembly
21
D1200014
1
Screw M8 x 10
22
D1200015
16
Screw M5x 18
23
D1200016
17
Lock Washer Φ5
24
D1200017
1
End Bearing
25
D1200018
1
Connecting Sleeve
26
D1200800
1
Gear Carrier Assembly （Output）
27
D1200900
1
Gear Carrier Assembly （Intermediate）
28
D1201000
1
Gear Sun Assembly （Intermediate）
29
D1200019
2
Gasket
30
D1200020
1
Gear—Ring
31
D1200021
1
Spring
32
D1200022
1
Steel Ball
33
D1200023
1
Screw M5 x 12
34
D1200024
1
Clutch Handle
35
D1200025
1
Clutch Axes
36
D1200026
1
Positioning Piece Of Clutch
37
D1200027
1
Clutch Seat
38
D1200028
1
Clutch Screw
39
D1200029
8
Flat Washer Φ5
40
D1200030
2
Locknut M10
41
D1201100
1
Roller Fairlead
42
D1200031
1
Mounting Channel
By Choice
43
D1201200
1
Remote Control Switch
44
D1201300
1
Cable Assembly
45
D1200032
1
Strap
46
D1201400
1
Control Section Of U Type Winch
By Choice
47
D1201500
1
Control Section Of S Type Winch
By Choice
48
D1201600
1
Control Section Of F Type Winch
By Choice
