Russell Hobbs 11 Series User Manual

P a g e | 6
11 Series Washing Machines Revision 1.6
INSTALLATION – TRANSPORTATION BOLTS
Before Installation, you MUST ensure the 4 transportation bolts are
removed. Failure to do so will result in damage to the appliance.
Using a 10mm spanner, turn the bolts counter clockwise until they
come loose from the white plug stoppers. Once removed, either
by hand or using plyers, remove the white plugs also.
Add the 4 blanking caps supplied into the holes left by the bolts.

Russell Hobbs 11 Series Specifications

General

Maximum Spin Speed	1400 rpm
Loading Type	Front Load
Delay Start	Yes
Quick Wash	Yes
Dimensions (HxWxD)	850 x 600 x 650 mm
