Russell Hobbs RHCM50

13
Filling by removing the water reservoir:
 Hold the water reservoir handle at a tilting angle
as shown in figure 2. to remove the water
reservoir from the appliance
 Fill the water reservoir up to the “MAX” level
mark with cold fresh water (the maximum
capacity is 0.8 litre), or fill at least the “MIN” level
mark
 Slide the water reservoir slowly on to the water
reservoir base. When the water reservoir outlet
is inserted on to the inlet receptacle, pushing it
firmly on the handle as shown in figure 3. to lock
the water reservoir into place
RINSING THE APPLIANCE AND ITS INTERNAL PIPING
1. Fill water reservoir to maximum level mark.
2. Plug the appliance in to the power outlet and
turn the appliance ON.
3. The lights on the control panel buttons will start
flashing. The blue lights in the used-capsule
container/ bin are showing blue. These will go
off after 1 minute. Tip: you can see when the
used capsule container/ bin are full when the
blue lights are on.
4. The round indicator light on the control panel
will flash red indicating first use. This means
that the internal circuit is empty. Please fill up
the water reservoir and open the operating
handle. Press any button to start the pump.
Once water is detected entering the internal
circuit, the red indicator light will turn blue.
5. The appliance will now start to heat up
automatically and all three (3) control panel
buttons will begin flashing.
Figure 2.
Figure 3.
