Russound CA4 - Controller Front and Rear Views

5
Russound CA4 System Installation Manual
CONTROLLER FRONT ANd REAR
Zone LED indicators
Power Indicator
Front Panel
Zone 4 Variable RCA Output
Audio Source inputs
Routed IR Outputs
RS232 Connection
RJ-45 Expander Jack
Wall Port RJ-45 Connections
12VDC Trigger
Common IR
Mute Input
Power Cord Connection
Zone 4 Fixed RCA Output
Rear Panel
