6.5.3.2 Unilateral jacking within vehicle profile
For example with the push-button „Left within profile“ the stabilizing jack
arms on the right side are extended together and in an horizontal way. On
the opposite side the stabilizing jack arm rest within the vehicle profile. As
soon as the stabilizing jack arms on the right side are horizontically fully ex-
tended, all jack cylinders drive out vertically.
Note
As long as no vertical movement of the stabilizing jacks has
started, you can change within the push button „Left within
profile“, „Right within profile“, „Full jacking“ or „Minimum jack-
ing“. The stabilizing jack arms will then be automatically
adapted to each jacking situation.
Attention!
Damage of jacking! Do not change the push button for
the jacks in case the jacks are vertically extended. A
jack cylinder, which is vertically extended, can damage
the jacking-system when e.g. when the jack-plate slides
on the ground or when it hits an edge!
Execution at operating panel
completely
horizontally
extension
Actuate push button „Left within pro-
file“ (keep depressed).
or
completely
horizontally
extension
Actuate push button „Right within pro-
file“ (keep depressed).
Jacks left and
Jacks right
afterwards
vertically
extension
