6.5.3.1 Full jacking
By means of the push-button „Full jacking“ all stabilizing-jack-arms are ex-
tended together horizontically. As soon as full horizontal extension is com-
pleted, the cylinders of the stabilizing-jacks are extended vertically.
Execution at operating panel
Jacks left and
Jacks right
completely
horizontally
extension
Actuate push button „Full jacking“
(keep depressed).
Jacks left and
Jacks right
afterwards
vertically
extension
The computer control system stops the movement automatically when:
all the stabilising jacks have contact with the ground,
the wheels of the vehicle are unloaded, i.e. lifted off the ground
and the electronically measured inclination of the Steiger is within the
permissible positioning inclination.
The inclination of the Steiger must at all events be controlled by means of the
levelling indicator!
Pilot lamps
„Jack front left“,
„Jack rear left“,
„Jack front right“,
„Jack rear right“
Pilot lamp, red
„Basic position“
