6.6.3 Boom movement
Remarks, instructions and pre-conditions of chapter „Operating the Steiger“
must be observed.
„Boom up“ or „Boom down“
Component
Movement /
Indication
Execution
Boom (lifting arm)
lifting
Actuate push button „boom up“.
or
Boom (lifting arm)
lowering
Actuate push button „boom down“.
Boom „rotation left“ or „rotation right“
Component
Movement /
Indication
Execution
Boom (Turret)
rotation left
Actuate push button „Rotation left“.
or
Boom (Turret)
rotation right
Actuate push button „Rotation right“.
„Telescope out“ or „Telescope in“
Component
Movement /
Indication
Execution
Telescope
extension
Actuate push button „Telescope out“.
or
Telescope
retraction
Actuate push button „Telescope in“.
