6 Operation
6-38
RUTHMANN-Steiger
®
TB270
BA.GB.12-27409-05-07-FTA-jr
6.6.4 „Cage rotation left“ or „Cage rotation right“
Component
Movement /
Indication
Execution
Working cage
rotation left
Actuate push button „Cage rotation
left“.
or
Working cage
rotation right
Actuate push button „Cage rotation
right“.
6.6.5 Adjustment of working cage inclination „Cage up/Cage down“
Component
Movement /
Indication
Execution
Working cage
move upwards
Actuate push button „Cage up“.
or
Working cage
move downwards
Actuate push button „Cage down“.
Note
As soon as the working cage reaches an inclination of more
than 10° to horizontal line, an emergency cut-off occurs.
