7 Emergency control system
(Emergency Lowering)
BA.GB.12-27409-05-07-FTA-jr
7.5 Manual adjustment of cage inclination
Danger!
Persons and things can fall out! If persons are in the
working cage you have to take special care. The work-
ing cage may only be positioned horizontally! The angle
of inclination must only be modified by hand pump op-
eration.
Switch main switch onto position „OFF“.
Open switch box (emergency control) at Steiger-substructure by means
of a key.
The vehicle engine must be switched off!
Release knurled screws of the cover at turret and remove the cover.
Take solenoid arresting device out of support in switch box at Steiger-
substructure.
Bring ball cock lever (switch box) into horizontal position.
Bring working cage into horizontal position.
Put solenoid arresting device according to chapter 7.3 onto sole-
noid head of way valve „Levelling up“.
Produce the pressure and volume flow of the hydraulic liquid by
means of the hand pump, until the working cage is in horizontal
position.
The speed can be regulated over the frequency of the pumping
movements.
Stop pumping movements when the horizontal position of the cage
is reached.
Remove solenoid arresting device immediately from the solenoid
head of the way valve.
Bring ball cock lever back into its vertical position.
Put solenoid arresting device back into its support.
Close cover of way valves, tighten knurled screws.
Close switch box at Steiger-substructure.
