9 Maintenance
9-10
RUTHMANN-Steiger
®
TB270
BA.GB.12-27409-05-07-FTA-jr
Plastic hydraulic oil tank
M
A
1
M
A
2
M
A
3
M
A
4
M
A
5
M
A
6
Threaded plug „connec-
tion hand pump“
Threaded plug „connec-
tion secondary drive“
(optional extra) or plug
screw
Screw plug
Oil draining screw
Return filter - hydraulic oil
tank
Connection flange suction
line - hydraulic oil tank
Rotating device
M
A
1
M
A
2
M
A
3
M
A
4
Hydraulic engine - stop-
ping brake
Stopping brake - worm
gear
Ball bearing slewing gear
- base frame
Ball bearing slewing gear
- turret plate
