9 Maintenance
BA.GB.12-27409-05-07-FTA-jr
RUTHMANN-Steiger
®
TB270
9-11
Bearing points with plastic bushes and bolt locks
Bearing point turret -
boom
Bearing point boom -
lifting cylinder
Further bolt locks
Bolt locks with disc and
countersunk screw
Bolt locks with disc and
countersunk screw
