0 General
0-10
RUTHMANN-Steiger
®
TB270
BA.GB.12-27409-05-07-FTA-jr
depending on the number of persons
in the cage, so that the max. carrying
capacity will not be exceeded.
Cage control
Operation of the Ruthmann-Steiger by
the operating staff from the working
cage.
Electrical locking device
To cancel certain movements / func-
tions.
Joystick
Control lever at control panel on work-
ing cage.
Push button (push function)
Push-button-actuated switch gears
with which the push button and the
corresponding contact element come
back into their initial position, after
releasing it.
Push button (push-to-lock-
function)
Push-button-actuated switch gears
with which the push button and the
corresponding contact element re-
mains as long in its pressed position
as a second switch movement releas-
es the locking itself and therewith a
shifting-over into the initial position is
effected.
Luminous push button
Push button switch with a transparent
push button and a lamp inside, which
indicated the switched position by
shining.
Warning / Pilot lamp
Signal lamp which indicates malfunc-
tions or switched positions by shining.
LED
Light-emitting diode
IDS
Information - and Diagnosis - System
Superordinate emergency
control system
A device, enabling you to bring the
working cage into its basic position in
case of a failure of the main driving
power. The movements are controlled
from the working cage (emergency
lowering).
Emergency control
Additional control device (emergency
control device) at substructure of the
