RUTHMANN Steiger TB270 - Page 53

2 Technical Specifications
BA.GB.12-27409-05-07-FTA-jr
RUTHMANN-Steiger
®
TB270
2-3
2.1.2 Details about the Steiger-superstructure
2.1.2.1 Main data
Working height
max. approx. 27,00 m
Lifting height (platform height)
max. approx. 25,00 m
Limitation of lifting height
Max. working programmable from
(programmable telescopic extension limita-
tion) (Optional extra)
approx. 11,00 m in steps of
approx. 1,00 m
Max. outreach with fully extended jacks
approx. 14,80 m
Maximum cage carrying capacity
230 kgs
Perm. lateral force
max. 400 N
Wind load
max. wind force 6
 windspeed
12,5 m/s
Perm. positioning inclination
max. 5°;
tyres ground clearance;
between 1° and 5° the out-
reach will be adapted auto-
matically
Inclination of ground to be levelled out (at
which a placing of the Ruthmann Steiger is
possible provided the permissible siting incli-
nation without supporting the jack plates is
kept)
lengthwise: approx. 8,9°;
crosswise: approx. 9,9°
Insulation
no
