2 Technical Specifications
BA.GB.12-27409-05-07-FTA-jr
RUTHMANN-Steiger
®
TB270
2-5
2.1.2.4 Working cage
Kind of the working cage
(Conditions when delivered)
aluminium working cage
Dimensions
approx. 1,40 m x 0,70 m
Height of protection
approx. 1,10 m
Maximum carrying capacity
230 kgs
Permissible number of persons
2
Permissible additional load
(Optional extras, tools and material must be
regarded as additional load!)
70 kgs
=
230kgs - 2 Persons (160kgs)
Entrance
front
(on the right in driving direc-
tion)
Socket
230 V / 16 A / 50 Hz
Socket
(Optional extra)
2-pole 12 V
Adjustable searchlight, demountable
(Optional extra)
12 V / 55 W
Connection for air-/water hose
(Optional extra)
Operating pressure
max. 150 bar
Temperature max. +80°C
Communication between working cage
and driver’s cab
no
Swivelling angle of working cage
approx. 2 x 90°
Insulation
no
