4 Operating elements and
displays
BA.GB.12-27409-05-07-FTA-jr
RUTHMANN-Steiger
®
TB270
4-11
1.
full jacking /
jack rear right
 - Jacking-variant with stabilizing jacks
extended horizontically on the left
and right.
- jacking on both sides within vehicle
profile after having reached the min-
imum jacking
- activates function key No. 27 for
control of rear right jack
1.
cage down
 - Working cage downwards
(inclination)
1.
cage up
 - Working cage upwards
1.
save position
 save a target position of the working
cage that has been moved into
1.
move into position
 move into a target position of the
working cage that has been saved
1.
free
 optional extra
1.
basic position
 move the Steiger into the basic posi-
tion automatically
1.
jack vertical down
 Only vertical extension of the stabiliz-
ing jack. Only in connection with
function key „jack rear left“, „jack
front left“, „jack front right“ and / or
„jack rear right“.
1.
Jacks up
 all stabilizing jacks drive in first verti-
cally, then horizontically
