4 Operating elements and
displays
4-10
RUTHMANN-Steiger
®
TB270
BA.GB.12-27409-05-07-FTA-jr
1.
boom down
 - Lowering of boom;
numerically marked with „5“
1.
special function
 switching the fine control on or off;
numerically marked with „6“
1.
free
 without function;
numerically marked with „7“
1.
free
 without function;
numerically marked with „8“
1.
rotation left
 - Rotate turret towards the left;
numerically marked with „9“
1.
cage rotation left
 - Rotate working cage to the left;
numerically marked with „0“
1.
cage rotation right
 - Rotate working cage to the right
1.
rotation right
 - Rotate turret to the right
1.
right within profile /
jack front left
 - Jacking variant with stabilizing jacks
extended horizontically on the left
side, on the right side within the ve-
hicle profile.
- jacking on both sides within vehicle
profile after having reached the min-
imum jacking.
- activates function key No. 27 for
control of front left jack
1.
page up
 scrolling of plain text indication, the
next „display page“ will be shown
1.
free
 without function
1.
left within profile /
jack front right
 - Jacking variant with stabilizing jacks
extended horizontically on the right
side, on the left side within the vehi-
cle profile.
- jacking on both sides within vehicle
profile after having reached the min-
imum jacking.
- activates function key No. 27 for
control of front right jack
1.
minimum jacking /
jack rear left
 - Minimum jacking.
- activates function key No. 27 for
control of rear left jack
1.
page down
 scrolling of plain text indication, the
previous „display page“ will be shown
1.
motor stop
 switch-off vehicle engine
