 4 rooms
UOMH36AFXZJ
No. Room 1 Room 2 Room 3 Room 4 Total
1
18*
1
18*
1
— — 36
2 7 7 15 — 29
3 7 7 18 — 32
4 7 7 24 — 38
5 7 9 12 — 28
6 7 9 15 — 31
7 7 9 18 — 34
8 7 12 12 — 31
9 7 12 15 — 34
10 7 12 18 — 37
11 9 9 9 — 27
12 9 9 12 — 30
13 9 9 15 — 33
14 9 9 18 — 37
15 9 12 12 — 33
16 9 12 15 — 36
17 9 12 18 — 39
18 12 12 12 — 36
19 12 12 15 — 39
20 7 7 7 7 28
21 7 7 7 9 30
22 7 7 7 12 33
23 7 7 7 15 36
24 7 7 7
18*
2
39
25 7 7 9 9 32
26 7 7 9 12 35
27 7 7 9 15 38
28 7 7 12 12 38
29 7 9 9 9 34
30 7 9 9 12 37
31 9 9 9 9 36
7: 7,000Btu/h, 9: 9,000Btu/h, 12: 12,000Btu/h, 15: 14,000Btu/h, 18: 18,000Btu/h,
24: 24,000Btu/h
*1: Optional kit RXK9FZ1818 shall be necessary for the dual zone system "18 + 18".
*2: Wall mounted type UIWH18AVFJ cannot be connected in this combination.
