6. Capacity table
6-1. Combinations
¢ Model: UOMH36AFXZJ
Cooling
Combination of indoor unit
Rated capacity for each indoor unit
(kBtu/h)
Maximum capacity for each indoor
unit (kBtu/h)
Total capacity
(kBtu/h)
Input power (kW)
Room 1 Room 2 Room 3 Room 4 Total Room 1 Room 2 Room 3 Room 4 Room 1 Room 2 Room 3 Room 4 Min. Rated Max. Min. Rated Max.
18 18 - -
36*
1
16.70 16.70 - - 18.00 18.00 - - 11.00 33.40 36.00 0.92 3.51 4.08
7 7 15 - 29 7.00 7.00 15.00 - 8.00 8.00 16.70 - 11.00 29.00 32.70 0.98 3.02 3.70
7 7 18 - 32 7.00 7.00 18.00 - 7.90 7.90 19.60 - 11.00 32.00 35.40 0.98 3.36 4.01
7 7 24 - 38 6.50 6.50 22.20 - 6.80 6.80 23.40 - 11.00 35.20 37.00 0.98 3.70 4.19
7 9 12 - 28 7.00 9.00 12.00 - 8.00 10.20 13.50 - 11.00 28.00 31.70 0.98 2.95 3.60
7 9 15 - 31 7.00 9.00 15.00 - 8.00 10.20 16.70 - 11.00 31.00 34.90 0.98 3.26 3.95
7 9 18 - 34 6.90 8.80 17.80 - 7.50 9.80 19.10 - 11.00 33.50 36.40 0.98 3.52 4.12
7 12 12 - 31 7.00 12.00 12.00 - 8.00 13.50 13.50 - 11.00 31.00 35.00 0.98 3.26 3.97
7 12 15 - 34 6.90 11.80 14.80 - 7.40 12.60 16.00 - 11.00 33.50 36.00 0.98 3.52 4.08
7 12 18 - 37 6.70 11.40 17.10 - 7.00 12.00 18.00 - 11.00 35.20 37.00 0.98 3.70 4.19
9 9 9 - 27 9.00 9.00 9.00 - 10.20 10.20 10.20 - 11.00 27.00 30.60 0.98 2.84 3.47
9 9 12 - 30 9.00 9.00 12.00 - 10.20 10.20 13.50 - 11.00 30.00 33.90 0.98 3.15 3.84
9 9 15 - 33 8.80 8.80 14.80 - 9.90 9.90 16.30 - 11.00 32.40 36.10 0.98 3.40 4.09
9 9 18 - 36 8.80 8.80 17.60 - 9.20 9.20 18.60 - 11.00 35.20 37.00 0.98 3.70 4.19
9 12 12 - 33 8.80 11.80 11.80 - 9.90 13.10 13.10 - 11.00 32.40 36.10 0.98 3.40 4.09
9 12 15 - 36 8.90 11.70 14.60 - 9.30 12.30 15.40 - 11.00 35.20 37.00 0.98 3.70 4.19
9 12 18 - 39 8.20 10.80 16.20 - 8.50 11.40 17.10 - 11.00 35.20 37.00 0.98 3.70 4.19
12 12 12 - 36 11.70 11.70 11.80 - 12.30 12.30 12.30 - 11.00 35.20 36.90 0.98 3.70 4.18
12 12 15 - 39 10.80 10.80 13.60 - 11.40 11.40 14.20 - 11.00 35.20 37.00 0.98 3.70 4.19
7 7 7 7 28 7.00 7.00 7.00 7.00 8.00 8.00 8.00 8.00 11.00 28.00 32.00 1.17 2.80 3.41
7 7 7 9 30 7.00 7.00 7.00 9.00 8.00 8.00 8.00 10.20 11.00 30.00 34.20 1.17 3.00 3.65
7 7 7 12 33 6.90 6.90 6.90 11.80 7.70 7.70 7.70 13.00 11.00 32.50 36.10 1.17 3.25 3.90
7 7 7 15 36 6.90 6.90 6.90 14.50 7.50 7.50 7.50 15.50 11.00 35.20 38.00 1.17 3.52 4.10
7 7 7
18*
2
39 6.30 6.30 6.30 16.30 6.80 6.80 6.80 17.60 11.00 35.20 38.00 1.17 3.52 4.10
7 7 9 9 32 7.00 7.00 9.00 9.00 7.80 7.80 10.00 10.00 11.00 32.00 35.60 1.17 3.20 3.78
7 7 9 12 35 6.90 6.90 8.90 11.80 7.50 7.50 9.70 12.90 11.00 34.50 37.60 1.17 3.45 4.06
7 7 9 15 38 6.50 6.50 8.40 13.80 7.00 7.00 9.00 15.00 11.00 35.20 38.00 1.17 3.52 4.10
7 7 12 12 38 6.50 6.50 11.10 11.10 7.00 7.00 12.00 12.00 11.00 35.20 38.00 1.17 3.52 4.10
7 9 9 9 34 6.90 8.90 8.90 8.90 7.70 9.90 9.90 9.90 11.00 33.60 37.40 1.17 3.36 4.04
7 9 9 12 37 6.70 8.60 8.60 11.30 7.20 9.20 9.20 12.40 11.00 35.20 38.00 1.17 3.52 4.10
9 9 9 9 36 8.80 8.80 8.80 8.80 9.50 9.50 9.50 9.50 11.00 35.20 38.00 1.17 3.52 4.10
NOTES:
•
*
1
: Optional kit RXK9FZ1818 shall be necessary for the dual zone system “18 + 18”.
•
*
2
: Wall mounted type UIWH18AVFJ cannot be connected in this combination.
• Specifications are based on the following conditions.
– Power source of specifications: 230 V
– 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 15: 14,000 Btu/h, 18: 18,000 Btu/h, 24:
24,000 Btu/h
– 3 or more indoor units should be connected. (Only the combinations of the “18 + 18” can
be connected by using the optional kit RXK9FZ1818.)
– Cooling: Indoor temperature of 80 °FDB (26.7 °CDB)/67 °FWB (19.4 °CWB), and outdoor
temperature of 95 °FDB (35 °CDB)/75 °FWB (23.9 °CWB).
– Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit—Indoor unit]
– The total ability of connected indoor units is from 27,000 Btu up to 39,000 Btu.
- 157 -
OUTDOOR UNIT
UOMH36AFXZJ
