Ruud UIWH07AVFJ - Accessories; 13-1.Wall Mounted Type

13. Accessories
13-1. Wall mounted type
¢
Models: UIWH07AVFJ, UIWH09AVFJ, UIWH12AVFJ, and UI-
WH15AVFJ
Part name Exterior Q’ty Part name Exterior Q’ty
Operating manual 1 Cloth tape 1
Installation manual 1
Tapping screw (large),
M4 × 25 mm
5
Wall hook bracket 1
Tapping screw (small),
M3 × 12 mm
2
Remote controller 1 Air cleaning filter 2
Battery 2 Filter holder 2
Remote controller
holder
1
Seal A
• It is necessary when
using 15 model.
• It is used when the
diameter of gas pipe
is Ø1/2 in (12.70
mm) or more.
1
DESIGN & TECHNICAL MANUAL
- 72 -
MULTI TYPE 2, 3, 4 ROOMS TYPE
