9. Safety devices
Indoor unit
type
Model name PCB* fuse
Fan motor thermal
protector
Terminal thermal
fuse
Float
switch
Wall mounted
UIWH07AVFJ
UIWH09AVFJ
UIWH12AVFJ
UIWH15AVFJ
250 V, 3.15 A
Activate: 221 ±18 °F
(105 ±10 °C)
Fan motor stop
Reset: 194 ±18 °F
(90 ±10 °C)
Fan motor restart
― ―
UIWH18AVFJ
UIWH24AVFJ
Activate: 302 ±27 °F
(150 ±15 °C)
Fan motor stop
Reset: 248 ±27 °F
(120 ±15 °C)
Fan motor restart
Activate: 216 °F
(102 °C)
―
*: Printed Circuit Board
DESIGN & TECHNICAL MANUAL
- 26 -
MULTI TYPE 2, 3, 4 ROOMS TYPE
