7-2. Sound level check point
¢
Wall mounted type
2 ft 7
-5/8
in (0.8 m)
3 ft 3
-3/8
in (1 m)
Microphone Microphone
NOTE: Detailed shape of the actual indoor unit might be slightly different from the one illustrated
above.
