Specifications
 Controller
Unit: in (mm)
Front view Side view Rear view
6-11/16 (170)
3/4 (19)
2-3/16 (56)
Top view
Size (H × W × D) in (mm) 6-11/16 × 2-3/16 × 3/4 (170 × 56 × 19)
Weight oz (g) 3 (85) (without batteries)
NOTE: Actual number of buttons might be different from the figure above.
 Holder
Unit: in (mm)
Front view Side view Bottom view
2-3/8 (60.4)
1-3/16 (30.2)
Ø1/8 (3.5)
1/8 x 1/4 (3.5 x 6.5)
(hole)
(hole)
1-1/16
1
3-3/4 (95)
6-1/16 (154.7)
(25.5)
(26.2)
Size (H × W × D) in (mm) 6-1/16 × 2-3/8 × 1-1/16 (154.7 × 60.4 × 26.2)
Weight oz (g) 10 (28)
