Specifications
 Controller
Unit: in (mm)
Top view
Front view Side view
8-1/16 (205)
11/16
(17)
2-3/8
(61)
Size (H × W × D) in (mm) 8-1/16 × 2-3/8 × 11/16 (205 × 61 × 17)
Weight oz (g) 4.3 (122) (without batteries)
 Holder
Unit: in (mm)
1-15/16 (48.5)
3/16 (5.5)
1-1/16
(26.2)
2-3/4 (69.3)
1/4 (6.5)
Front View Side View
Bottom View
Ø 1/8
(Ø3.5)
(Hole)
5-7/8 (150)
4-3/16 (106.8)
Hole
(1/83.5)
2-R
Size (H × W × D) in (mm) 5-7/8 × 2-3/4 × 1-1/16 (150 × 69.3 × 26.2)
Weight oz (g) 1 (27)
