Electric Fireplace
RFH-3001LA(B) / RFH-3601LA(B) / RFH-4001LA(B) / RFH-4201LA(B) /
RFH-4801LA(B) / RFH-5001LA(B) / RFH-6001LA(B/H) / RFH-7401LA(B) / RFH-10201LA(B)
NO VENTING REQUIRED
WARNING
Read and understand this entire owner's manual, including all safety information
before plugging in or using this appliance. Failure to do so could result in fire, electric
shock, or serious personal injury.
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS: ETL
IMPORTANT INSTRUCTIONS
AND OPERATING MANUAL
9733 Topanga Canyon Blvd. APT310, Chatsworth, CA 91311
Phone: 213-4467172

Table of Contents

Questions and Answers

  • B
    Belinda MejiaAug 14, 2025
    Why won't the heater on my RW Flame RFH-3001LA Indoor Fireplace turn on with the power switch?
    • L
      Laura DavilaAug 14, 2025
      The heater might not be turning on for several reasons. First, ensure the main power supply switch is in the "ON" position. Check if the circuit breaker has tripped, indicating too many appliances on the circuit; this unit should have its own individual circuit. Verify the power cord is securely plugged into a functioning and properly grounded 15 Amp 120V AC electrical outlet. Also, the power cord or plug could be damaged, requiring a qualified electrician to replace the cord. The power outlet might be loose and need replacement, or there could be loose wiring requiring inspection and repair by a qualified electrician.
  • B
    Billy GilbertAug 17, 2025
    What to do if my RW Flame Indoor Fireplace heater system doesn't come on?
    • S
      Stephen PowellAug 17, 2025
      If the heater system isn't turning on, first ensure the heater power switch is in the "ON" position. The system may have overheated; if so, it might be covered, or the air inlet/outlet could be blocked. Remove any obstructions, turn off the power switch, unplug the unit, wait 10 minutes, and then try turning it on again. Also, check for loose wiring, which should be inspected by a qualified electrician. Ensure there is adequate space around the unit and remove any blockages from the air inlet or outlet.
  • T
    Tracy McmahonAug 20, 2025
    Why is there no airflow from my RW Flame RFH-3001LA when the 'HEAT' switch is on?
    • S
      shannonstewartAug 21, 2025
      If there's no airflow when the 'HEAT' switch is on, the heater system may be overheated, causing the temperature limit thermostat to cut off. Check the air inlet and outlet, then turn off the power switch, unplug the unit, wait 10 minutes, and turn it back on. Also, make sure both the 'POWER' and 'HEAT' switches are turned on.
  • K
    Kristopher RoachAug 23, 2025
    How to fix a RW Flame RFH-3001LA with heater on, but no flame or low flame intensity?
    • C
      Carl WebbAug 25, 2025
      If the heater is on but the flame is missing or weak, try long-pressing the "DIMMER" button for 6 seconds to ensure the appliance is not in sleep mode (all lights off, heating on). Press and hold again for 6 seconds to return to normal mode. Also, check that the Flame Adjusting knob is set to the maximum. Finally, loose wiring could be the issue, so consult a qualified electrician to check all wiring connections.
  • J
    jenniferlindseyAug 27, 2025
    What to do if my RW Flame RFH-3001LA has a sudden power outage during heating?
    • M
      Michelle GrahamAug 27, 2025
      If you experience a sudden power outage during the heating process, make sure you are not covering the air outlet. Unplug the unit, wait 10 minutes, and then try turning it on again.
  • J
    Justin SchultzAug 30, 2025
    How do I fix my RW Flame Indoor Fireplace remote control if it's not working?
    • M
      Mark DavisAug 30, 2025
      If the remote control isn't working, first ensure the battery is correctly installed and that you've removed the transparent insulating piece. Aim the remote control directly at the receiver. Remove any obstacles between the remote and the machine that may be blocking the signal. Finally, avoid pressing the remote control buttons too quickly; allow the unit time to respond to each command.
  • J
    Jessica SmithSep 3, 2025
    What to do if the control panel functions on my RW Flame RFH-3001LA Indoor Fireplace do not work?
    • H
      Henry WilliamsSep 3, 2025
      If the control panel functions aren't working, first ensure the Power Switch on the control panel is turned on. Also, make sure you have reconnected the data cable which was pulled out when you removed the glass frame.
  • A
    Alyssa LopezSep 6, 2025
    How to remove the mounting bracket from RW Flame Indoor Fireplace?
    • M
      Mariah WilsonSep 6, 2025
      To remove the mounting bracket, unscrew the two screws on both sides of the fireplace using a Phillips screwdriver, then remove the pre-attached mounting bracket.
  • R
    Roy PhillipsSep 9, 2025
    Why is there an odor coming from my RW Flame RFH-3001LA Indoor Fireplace heater?
    • A
      anne67Sep 9, 2025
      The heater may emit a slight, harmless odor when first used. This is normal due to the initial heating of internal parts and will not occur again.

Summary

Important Safety Instructions

Safety Precautions and Usage Guidelines

Covers warnings, handling, placement, and electrical safety to prevent fire, shock, and injury.

Packing List

Included Components

Lists all items included in the package, such as the front frame, fireplace unit, manual, and remote control.

Hardware Details

Details of included hardware parts (A-F) with descriptions, quantities, and applicable models.

Dimensions and Specifications

Product Dimensions

Provides detailed measurements (mm and inches) for various models of the electric fireplace.

Wall Mounting Clearance

Notes on required space for power cord placement on the right side of the fireplace.

Listing Approvals

ETL Certification

Information on ETL standards compliance for fixed and location-dedicated electric room appliances in the US and Canada.

Electrical Installation Notes

General Electrical Safety and Setup

Covers initial setup, precautions for hot surfaces, surge protectors, and power cord handling.

Installation Instructions

General Installation Guidelines

Follows national/local codes, specifies clearances, and notes on placement and unattended use.

Unpacking and Initial Testing

Instructions for carefully removing the appliance and testing its operation before installation.

Appliance Grounding

Explains grounding methods for 120V appliances and the use of adapters for different outlets.

Assembly Options

Wall Hanging: Introduction

Overview of wall hanging installation option and its initial steps.

Wall Hanging: Removing Glass Frame

Instructions for safely removing the glass frame from the fireplace unit.

Wall Hanging: Bracket Installation

Steps for removing the bracket, selecting a wall location, and attaching it.

Wall Hanging: Securing Fireplace

Instructions on hanging and locking the fireplace securely onto the installed mounting bracket.

Built-in: Frame and Bracket Removal

Steps for removing glass frame and mounting bracket for built-in installation.

Built-in: Cavity Preparation and Fixing

Attaching foot pads and preparing the wall cavity for the fireplace.

Built-in: Securing Fireplace in Cavity

Drilling anchors, placing pads, and fastening fireplace into the prepared wall cavity.

Built-in: Final Attachment

Instructions for final glass frame attachment for built-in installation.

Finishing Touches

Important Finishing Warnings

Covers hot grille warnings, door hook safety, clearance for airflow, and handling the glass front.

Operating Instructions

Main Power Button Operation

Locates and describes the function of the main power button on the fireplace unit.

Control Panel and Remote Operation

Overview of the touch display panel and remote control functions for operating the fireplace.

Function Controls Explained

Detailed explanation of controls for Power, Dimmer, Timer, Flame Speed, Heater, and Colors.

Remote Control Usage

Instructions on preparing and using the remote control for the fireplace.

Troubleshooting Guide

Common Issues and Solutions

Addresses problems like mounting bracket removal, control panel issues, and power outages with solutions.

Operation and Flame Issues

Resolves issues like heater not turning on, no flame, or low flame intensity.

Airflow, Heating, and Odor Problems

Solutions for no airflow, no heat, remote control malfunctions, and initial odors.

Maintenance

Cleaning the Glass

Instructions for cleaning the partially reflective glass using a dry or damp lint-free cloth.

Schematic Diagram

Provides a wiring diagram of the fireplace components for technical reference.

Limited Warranty

Warranty Terms and Conditions

Details the one-year warranty, coverage, exclusions, and conditions that void the warranty.

RW Flame RFH-3001LA Specifications

General IconGeneral
BrandRW Flame
ModelRFH-3001LA
CategoryIndoor Fireplace
LanguageEnglish
