ryan REN-O-THIN 544865B - Page 25

1/8” FIXED BLADE REEL 14
21
Ref.
No.
Part
No.
Description Notes
No.
Req’d
1 305134 Nut, jam, 7/8–14 2. . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 516898 Blade, 1/8” (3.2 mm) 13. . . . . . . . . . . . . . . . . . . . . . . .
3 516904 Spacer, .700 (19.6 mm) 14. . . . . . . . . . . . . . . . . . . . .
4 516905 Spacer, .900 (23 mm) 12. . . . . . . . . . . . . . . . . . . . . . .
5 517148 Shaft 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 545640 Pillow block, complete 2. . . . . . . . . . . . . . . . . . . . . . .
7 548101 •Bearing, ball 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 521857 ••Collar, locking 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9 548176 ◊Washer, flat 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10 820484 ◊Washer, flat 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1/8” (3 mm) FIXED BLADE REEL
• INDENTED PARTS NAMES INDICATE THESE PARTS ARE INCLUDED IN PRECEDING ASSEMBLY
◊ Use washers as required so that the nut (ref. no. 1) will not contact hex shaft when tight.
