The model number will be found on the data plate attached to the right side panel of the cabinet, next to the saw’s on board receptacle. Always
mention the model number in all correspondence regarding your TABLE SAW or when ordering repair parts.
RYOBI 10 in. (254 mm) TABLE SAW – MODEL NO. BT3100
PARTS LIST FOR FIGURE 64
KEY
NO. DESCRIPTION QUAN.
1 Leveling Foot ............................................................................................................................................................................ 4
2 Hex Nut .................................................................................................................................................................................... 32
3Washer .................................................................................................................................................................................... 32
4 Carriage Bolt............................................................................................................................................................................ 24
5 Leg ............................................................................................................................................................................................. 4
6 Upper Brace .............................................................................................................................................................................. 2
7 Screw ........................................................................................................................................................................................ 4
8 Hex Nut ...................................................................................................................................................................................... 8
9 Upper Side Brace ...................................................................................................................................................................... 2
10 Lower Leg Brace ....................................................................................................................................................................... 4
11 Storage Bracket ......................................................................................................................................................................... 4
12 Washer .................................................................................................................................................................................... 12
13 Bolt ............................................................................................................................................................................................ 4
Stand Fastener Package ........................................................................................................................................................... 1
