11
FEATURES
SPINDLE LOCK BUTTON
See Figure 3.
The spindle lock button locks the spindle stopping the
blade from rotating. Depress and hold the lock button while
installing, changing, or removing blade.
SWITCH TRIGGER
See Figure 4.
The saw will not start until you depress the switch lock with
your thumb then squeeze the switch trigger. To prevent
unauthorized use of the compound miter saw, disconnect it
from the power supply and lock the switch in the off position.
To lock the switch, install a padlock (not included) through
the hole in the switch trigger. A lock with a long shackle of
5/16 in. diameter may be used. When the lock is installed
and locked, the switch is inoperable. Store the padlock key
in another location.
The following tool (not included) is needed for making adjustments or installing the blade:
TOOLS NEEDED
Fig. 5
SQUARE
Fig. 4
PADLOCK
SWITCH
TRIGGER
SWITCH
LOCK
