RYOBI 10 in. (254 mm) COMPOUND MITER SAW – MODEL NO. TS1340
S58000500 BASE AND TABLE ASSEMBLY
1 580118000 FENCE............................................................................................ 1
2 A07103080457 * SOCKET HEAD CAP SCREW (M8 X 45 mm) ................................. 4
3 A36030814204 * SPRING WASHER (M8) .................................................................. 4
4 A19003040093 * PANCROSS SCREW (M4 X 9 mm) ................................................. 2
5 518106300 TABLE SPINDLE............................................................................. 1
6 A35031025153 * FLAT WASHER (M10) ..................................................................... 2
7 A36131020100 * SPRING WASHER (M10) ................................................................ 1
8 A31703010008 * SELF-LOCKING NUT (M10) ............................................................ 1
9 A36030612157 * SPRING WASHER (M6) .................................................................. 2
10 A07003060257 * SOCKET HEAD CAP SCREW (M6 X 25 mm) ................................. 2
11 518104200 CONTROL ARM .............................................................................. 1
12 518103100 LOCK HANDLE ............................................................................... 1
13 580114000 POINTER ........................................................................................ 1
14 A35030410018 * FLAT WASHER (M4) ....................................................................... 1
15 A10003040107 * PANCROSS SCREW (M4 X 10 mm) ............................................... 1
16 518105400 LOCK PLATE .................................................................................. 1
17 A49001020056 RIVET ............................................................................................. 3
18 580119000 MITER SCALE ................................................................................ 1
19 580117000 BASE .............................................................................................. 1
20 580120000 FIXED CAP ..................................................................................... 1
21 511104000 TABLE HOLD DOWN ...................................................................... 1
22 518A08130 VISE CLAMP ASSEMBLY .............................................................. 1
23 512106000 TABLE............................................................................................. 1
24 589027202 TABLE INSERT............................................................................... 1
25 A16003040083 * SCREW (M4 X 8 mm)...................................................................... 4
The model number will be found on a plate attached to the motor housing. Always mention the model number
in all correspondence regarding your Compound Miter Saw or when ordering repair parts.
PARTS LIST - FIGURE A
Key Part
No. Number Description Qty.
* Standard Hardware Item — May Be Purchased Locally
