Ryobi TS1343L Repair Sheet

RYOBI 10 in. COMPOUND MITER SAW – MODEL NUMBER TS1343L
3
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence
regarding your MITER SAW or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY.
FIGURE A PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 080006014904 Cord Wrap Warning Label (Fr/Sp) .............................. 1
2 080006014056 Cord Assembly ........................................................... 1
3 089100207100 Bend Relief ................................................................. 1
4 089100200129 Cord Clamp ................................................................ 1
5 089100207087 Screw (M4 x 16 mm, Pan w/Washer Hd.) .................. 7
6 080009002068 Screw (M3 x 12 mm) .................................................. 1
7 080006014706 D-Handle Assembly ................................................... 1
8 080006014074 Screw (M5 x 20 mm) .................................................. 2
9 080009004038 Screw (M3 x 8 mm, Pan Hd.) ..................................... 1
10 080006014057 Battery Compartment ................................................ 1
11 089240001065 Laser Switch .............................................................. 1
12 080006014062 Battery Box Cover ...................................................... 1
13 080006014061 Screw (M4 x 10 mm) .................................................. 1
14 089240001052 Screw (M5 x 30 mm, Pan Hd.) ................................... 2
15 089100207090 Switch Actuator ......................................................... 1
16 080006014060 Compression Spring .................................................. 1
17 089100207098 Switch ........................................................................ 1
18 080006014053 Screw w/Washer (M5 × 65 mm, Pan Hd.) .................. 2
19 080006014703 Field Assembly ........................................................... 1
20 080009002077 Brush .......................................................................... 2
21 080006014901 Data Label .................................................................. 1
22 080006014048 Holder Cap ................................................................. 2
23 080009002078 Brush Holder .............................................................. 2
24 080006014047 Motor Housing ........................................................... 1
25 080009005116 Screw (M5 × 5 mm, Set) ............................................ 2
26 080009002080 Screw (M5 × 6 mm, Set) ............................................ 2
27 080006014902 Warning/Danger Label ............................................... 1
28 080006014709 Motor Housing Assembly (Inc. Key Nos. 18-27) ........ 1
29 080006014046 Screw (M5 x 35 mm, Pan Hd.) ................................... 4
30 080009002086 Ball Bearing (6200TU/TZ/CM/5C) .............................. 1
31 080009002085 Ball Bearing (608 2RS C3) ......................................... 1
32 080006014705 Armature Assembly (Inc. Key Nos. 30-31) ................. 1
33 080006014037 Baffle .......................................................................... 1
34 080009002053 O-Ring ........................................................................ 1
35 080006014038 Spindle Lock Pin ........................................................ 1
36 089100207065 Compression Spring .................................................. 1
37 089100207066 E-Ring ........................................................................ 1
38 080006014702 Arm Assembly (Inc. Key Nos. 34, 42, 44 and 55) ...... 1
39 089100208104 Screw (M5 x 8 mm, Set) ............................................. 2
40 080006014049 Laser Cover ................................................................ 1
41 080006014050 Screw (M4 x 6 mm, Pan Hd.) ..................................... 1
42 080006014906 Logo Label ................................................................. 1
43 089100207047 Stop Block ................................................................. 1
44 080009002050 Needle Bearing .......................................................... 1
45 080006014042 Gear ........................................................................... 1
46 080006014043 Lock Ring ................................................................... 1
47 080009002055 C-Ring (STW15) ......................................................... 1
48 080009005104 Bearing Cover ............................................................ 1
49 089100302119 O-Ring ........................................................................ 1
50 080009002056 Ball Bearing (6002TU/TZ/CM/5C) .............................. 1
51 080006014044 Gear Shaft .................................................................. 1
52 080009002913 Gasket ........................................................................ 1
53 089240001044 Bearing Holder Plate .................................................. 1
54 080006014710 Arbor Assembly (Inc. Key Nos. 45-53) ....................... 1
55 080006014908 Pivot Plate Screw Warning Label ............................... 1
56 089100207027 Screw (M3) ................................................................. 1
57 080006014708 Linkage Assembly ...................................................... 1
58 089100207028 Lock Nut (M6) ............................................................. 1
59 089100207031 Washer (D6 x D16 x 1t) .............................................. 1
60 089100207102 Retaining Ring ............................................................ 1
61 089100207103 Guide Roller ............................................................... 1
62 080006014063 Lower Guard .............................................................. 1
63 089100207097 No Hands Warning Label ........................................... 1
64 080006014066 Return Spring ............................................................. 1
65 089100207051 Blade Direction Warning Label .................................. 1
66 080006014064 Rotating Cover ........................................................... 1
67 089100207039 Screw (Special) .......................................................... 1
68 080006014707 Lower Blade Guard Assembly
(Inc. Key Nos. 57-67) ................................................. 1
69 089240001064 Screw (M5 x 10 mm, Shoulder) .................................. 1
70 A19001040091 Screw (M4 x 9 mm, Pan Hd.) ..................................... 1
71 089100207042 Arbor Blade Bolt ........................................................ 1
72 089100207043 Flange ........................................................................ 2
73 089100207045 Blade (Carbide - 10 in. x 24t) ..................................... 1
74 080006014027 Dust Bag Assembly .................................................... 1
75 080006014026 Screw (M4 x 12 mm, Pan Hd.) ................................... 1
76 089100208108 Screw (M4 x 20 mm, Pan Hd.) ................................... 2
77 089240001093 Screw (M4 x 16 mm, Pan Hd.) ................................... 2

Ryobi TS1343L Specifications

General

Brand	Ryobi
Model	TS1343L
Category	Saw
Language	English
