27 — English
OPERATION
CUTTING WARPED MATERIAL
See Figures 32 - 33.
When cutting warped material, always make sure it is
positioned on the miter table with the convex side against
the fence as shown in figure 32.
If the warped material is positioned the wrong way as shown
in figure 33, it will pinch the blade near the completion of
the cut.
WARNING:
To avoid a kickback and to avoid serious personal injury,
never position the concave edge of bowed or warped
material against the fence.
CLAMPING WIDE WORKPIECES
See Figure 34.
When cutting wide workpieces, such as nominal 2 in. x 6
in., boards should be clamped with a C-clamp as shown in
figure 34.
RIGHT
Fig. 32
Fig. 33
Fig. 34
WRONG
WIDE
BOARD
