Ryobi TSS121 - Warped Material and Wide Workpieces

35 − English
OPERATION
Fig. 42
RIGHT
CUTTING WARPED MATERIAL
See Figures 42 - 43.
When cutting warped material, always make sure it is
positioned on the miter table with the convex side against
the fence as shown in figure 42.
If the warped material is positioned the wrong way as shown
in figure 43, it will pinch the blade near the completion of
the cut.
WARNING:
To avoid a kickback and to avoid serious personal injury,
never position the concave edge of bowed or warped
material against the fence.
CLAMPING WIDE WORKPIECES
See Figure 44.
When cutting wide workpieces, such as a nominal 2 in.
x 6 in., boards should be clamped with a work clamp as
shown in figure 44.
WIDE
BOARD
Fig. 43
Fig. 44
WRONG
