POSITION DESCRIPTION CODE
1 PRE-FILTER COVER HD006000
2 PRE-FILTER BASKET WITH HANDLE HD018000
3 PRE-FILTER JOINT COVER HD021000
4 PUMP BODY SCREW M8X65 (4 PCS) HD026055
5 WASHER DIN 125 M8 (4 PCS) HD031010
6 NUT M8 (4 PCS) HD031055
7 DRAIN PLUG 1/4” HD036000
8 DRAIN PLUG OʼRING 13X2,5 HD021100
9 PUMP BODY HD041000
10 DIFFUSER JOINT HD021035
11 DIFFUSER 0,33 / 0,50 / 0,75 / 1 HP HD046000
11 DIFFUSER 1,50 HP HD046005
12 IMPELLER FIXING NUT M10 HD031075
13 IMPELLER 0,33 HP HD051005
13 IMPELLER 0,50 HP HD051010
13 IMPELLER 0,75 HP HD051015
13 IMPELLER 1 HP HD051025
13 IMPELLER 1,50 HP HD051035
14 PUMP BODY JOINT HD021060
15 MECHANICAL SEAL Ø15 HD056005
16 PUMP BODY LID 0,33 / 0,50 HP 1-PH HD061000
16 PUMP BODY LID 0,75 HP / 1 HP / 1,50 HP 1-PH/3-PH HD061005
17 PUMP BASE HD066000
18 SILENT-BLOCK (16x45x13) 0,33 / 0,50 HP HD071005
18 SILENT-BLOCK (9x45x13) 0,75 / 1 / 1,50 HP HD071000
19 V-RING JOINT VA-14 (2 PCS) MT001000
20 MOTOR FLANGE 0,,33 / 0,50 HP 1-PH MT006025
20 MOTOR FLANGE 0,75 / 1 / 1,50 HP 1-PH/3-PH MT006050
21 BALL-BEARING (6202) 0,33 / 0,50 / 0,75 / 1 / 1,5 HP (2 PCS) MT026000
22 ROTOR WITH SHAFT 0,33 HP MT031000
22 ROTOR WITH SHAFT 0,50 HP MT031005
22 ROTOR WITH SHAFT 0,75 HP MT031010
22 ROTOR WITH SHAFT 1 HP MT031015
22 ROTOR WITH SHAFT 1,50 HP MT031020
23 HOUSING + STATOR 0,33 HP 1-PH MT043000
23 HOUSING + STATOR 0,50 HP 1-PH MT043005
23 HOUSING + STATOR 0,75 HP 1-PH MT043020
23 HOUSING + STATOR 0,75 HP 3-PH MT043025
