Automatic Backflush Filter F450
State: 05.02.2016 – 1.3 Georg Schünemann GmbH, Bremen 6-2
6.3 Pneumatic cylinder
After removing the flushing disc the pneumatic cylinder may be completely
removed by loosening the four flange screws on the cover and inspected for
damage.
6.4 Seals
The cover seal is accessible if the filter is open and may be inspected of
damages and replaced if necessary.
The seals for the piston rod lead-through are accessible when the pneumat-
ic cylinder has been removed and may be inspected of damages and re-
placed if necessary.
Please note, the spacer always has to be installed above the rod seal!
The component parts described above are always subsequently assembled in
reverse order.
