Automatic Backflush Filter F450
State: 05.02.2016 – 1.3 Georg Schünemann GmbH, Bremen 8-1
8 Disassembly and disposal
8.1 Disassembly
The compressed air unit is to be set out of operation and into pressure-free con-
dition. The compressed air unit is safeguarded against unintentional repressuring
and marked by a sign „Work on compressed air unit“. Additionally also the elec-
trical system is to be set out of operation and safeguarded against resetting.
The following steps have to be enforced:
Interrupt the electrical and pneumatic supply lines
Make the pipes and the filter pressure-less and discharge them
Attach the filter securely against slipping at the flanges and prestress lightly
with a suitable and technical proper lifting tool
Loose the flange connections
Lift the filter carefully and pull it out of the piping under observance of ade-
quate safety clearance
8.2 Disposal
After the disassembly a professional disposal of all unusable or not further used
components can take place. The regulations and terms for disposal of compo-
nents of machines, which are valid at the term of disassembly, have ever to be
considered, independent of the following regulations for disposal!
8.2.1 General regulations for disposal
Flushing disc,
orifice etc.
