Note:
For Fairbanks recoil starter, place starter hub with washer and retaining plate 1n
position, hold it with strap spanner and secure it with nut M 14 x 1.5.
Torque 5.4 .. . 6.0 kpm (39.1 ... 43.4 ft. lb . ).
For recoil s tarter with friction jaws, place starter hub and washer in position, hold it
with pin spanner (repa ir tool no. 7) and secu re it with collar nut M 14 x 1.5.
Torque 5.4 .. . 6.0 kpm (39.1 . .. 43.4 ft. lb. ).
Secure recoil starter with 6 nuts M 6 and spring washers.
Electric starter, carburettor and intake silencer
Screw on electric starter .
Screw on ine rtia-pinion type starter with 2 nuts M 8 and spring washers.
Screw on solenoid-controlled starter with 2 nuts M 8 and spring washers. Screw
additional supporting plate on to crankcase p. t. o. side with two he x agon head
screws M 8 x 20 and washers .
Connect impulse pipe (4, Fig. 1) to connection on crankcase.
Place on both insulating bushes, insulat i ng flange, carburettor (fit impulse pi pe to
connection on carbu r ettor) and both fibre washers (hard cloth s id e towards carbu-
rettor) and sc re w carburettor fi rmly into pl ace with 2 self - locking nuts M 6.
Note:
On SACHS SA 280 A there is an intake stack between corburettor and cylinde r.
Secure cover plate (2, Fig. 1) and adapter flange with 3 cylindrical screws
1
/ 4' x 15 and
spring washers to carburet t or and secure intake sile nc er (1, Fig. 1} .
On e ngin es with intake s il encer (Fig. 302 , page 53}, secure cove r plate and i ntake
manifold with 2 cy lin drical screws
1
/4 ' x 55 and 1 cylindrical
1
/4 ' x 30 and spr i ng
wash ers to carburettor. Secure intake silenc e r with 2 hexagon screws M 6 x 15 and
spring wa she rs to fan hou s ing .
Exhaust muffler
Screw on exhau st muffler or manifold and bracket respectively.
40
