11
1
2
5
3
4
NOTE
The tank cap (1) is located behind the
seat.
Tank cap
OVERVIEW AND OPERATION
Unlock:
- Turn the cover (2) to the left or right
side.
- Insert the ignition key in the lock (3) turn
to the left and open the tank cap (4).
Lock:
- The marks (5) must be in front before
closing the tank cap.
- Close the tank cap by turing with the igni-
tion key to the right and pull out the key.
- Close the cover (2).
