Sachs Speedforce 50 - Lubricating Oil Tank

12
4
3
1
2
1
OVERVIEW AND OPERATION
Lubricating oil tank
CAUTION
Check the oil level during every tanking
and replenish if necessary.
If the oil level is too low, the indicator (1
) will light up. Replenish two stroke
oil within the next 50 km.
Damage caused by not observing this
instruction will not be covered under
warranty.
Filling up with lubricating oil
- Use only mineral - or semi-synthetic oil
for separate injection:
API-Norm TC, JASO-Norm FC.
- Insert the ignition key in the lock (1) turn
to the left and open the inspection cover
(2).
- Open the oil cap (3) and replenish max.
to the mark (4) of the oil fi ller.
- Tighten the oil fi ller cap by hand.
- Lock the inspection cover (2) with in igni-
tion key.
