NOTES ON MAINTENANCE
Cleaning the air fi lter
NOTE
The scooter is attached with a oil foam air
fi lter. In case of heavy dirtiness the foam
(11) has to be replaced.
.
Disassembly and cleaning
- Open the seat (1).
- Remove the screws (2) and take off the
storage box (3) together with the seat.
- Disconnect the hose (4) from the air
fi lter housing.
- Remove the clamp (5) from the carbu-
rettor and disconnect the manifold (6).
